Products Description
Automatic Instant Noodle production line, with perfect technology, compact structure, original design and
stable performance, is developed on the base of similar products and requirements in the world market.
We have mature production technology and process, combined with the advanced noodle manufacturing technology brought by Japan Noodle. The company's equipment models are complete, reliable quality, beautiful appearance, reasonable design, both small investment, suitable for small and medium-sized production equipment for small enterprises. There are also large and medium-sized equipment with high degree of automation, advanced technology, large output and good product quality.
Automatic fried instant noodles production line cost is relatively high, the labor demand is lower, the degree of automation is high, and it is also liked by customers.
Process Flow
Flow chart of fried Instant Noodle production line :
Weighing, pneumatic conveying, brine making - biaxial and - Xing surface transport - monolithic calender - three steamed noodles - cut fold - Fried dehydrated, wind cooling, packaging
Dough maker
Power: 2.2KW, liquid supply pump 1.1KW
Specification: 1000×1000×1220 square, volume 1000L
Configuration: infusion pipe DN40, pump, valve, helical gear reducer
Material: 304 stainless steel: sanitary pipe fittings, joints, pumps, valves, barrels
brine metering device
1 set
Specification: 377×1000 volume 110L round
Configuration: Infusion pipe DN40, pump, valve stainless steel
Material: 304 stainless steel: sanitary pipe fittings, joints, pumps, valves, barrels
Two-axis flour mixer
A set
The pan length is 1600,200kg/time
Configuration: Flat pan teeth, manual rotary door, manual pouring powder
Material: pot body, pot teeth, guard stainless steel; Transmission parts carbon steel, base carbon steel outside stainless steel.
Rongmian conveyor
A set
Configuration: helical gear reducer
Specification: Belt circumference 7 meters, width 500mm.
Material: box frame, protective plate stainless steel; Bracket, stepladder carbon steel
Square face cutting and sorting machine
The cutting speed is 50 times/min, three rows are divided into nine rows, and the length of the row is about 2 meters
Configuration: 1 air knife, 1 spray pipe, 1 water tray and 1 sink.
Material: frame, mesh belt, shaft 304 stainless steel production, split sheet silica gel, transmission parts carbon steel.
Single sheet calender
Specification: Roll width 270mm, 7 sets of roller, with 300×1, 248×1, 216×2, 180×1, 126×2
Configuration: helical gear reducer, hand wheel with watch, 30mm machine side, copper scraper, rod feeding, single-side adjusting piece, 2 square knives, 1 set of swing molding device.
Material: shield stainless steel; Alloy roller, nylon protection plate; Frame carbon steel, transmission carbon steel.
fryer
Square face, 70g/block, frying time: 90s
Configuration: 1 set of 60㎡ spiral plate heat exchanger, 1 set of face box and face cover, 1 set of portable slag remover, three ways of oil inlet, automatic oil filling, automatic temperature control.
Material: Stainless steel: guard plate, cover, drain cylinder, face box, face cover
Carbon steel: pot body, bracket, chain, track, pipe, valve, heat exchanger
One oil storage tank
Multi-layer noodle steamer
Configuration: one pressure reducing valve, stainless steel mesh belt, chain, track,
Tide exhaust duct 8 m *2, including brush screen device.
Material: Internal 316, other 304 made
finisher
Configuration: nailing climbing type, slag plate, oil plate each 1
Material: chain push rod, slag tray, oil tray, frame stainless steel
Air cooler
6 meters long
Configuration: 1 set of mesh belt, air duct 8 meters
Material: frame body, protection plate, duct stainless steel; Transmission parts, chain carbon steel.
We can provide the electronic edition certificates for instant noodle machine if asked, or you can see the original documents in our factory. We can ensure the truth of our certificates.
Production Line Details
Three phases of indomie noodle production line: 380 V/50 Hz, Single phase: 220 V/50 Hz in china, we can make it according to
customers' local voltage in different countries.
Automatic Instant Noodle production line
Instant Noodles Instant noodles are made from wheat flour, starch, water, salt or kan sui (an alkaline salt mixtureof sodium carbonate, potassium carbonate, and sodium phosphate), and other ingredients that improve the texture and flavor of noodles.The machine is based on many years to produce the experience of a variety of pressing machine, and the use of the shortcomings, the essence of all within the industry to develop new products, with the advantages of reasonable structure, beautiful and practical, and high efficiency of the pressure surface, and smooth operation, low noise.
Features of Noodle Making Machine:
1. Modeling space, low noise, easy to operate, easy to understand.Full cast steel gear transmission, all bearing rolling, automatic cross-section, automatic rod.
2. All-steel gear transmission, all bearings, small size, compact structure.Automatic transmission, a molding, automatic cross-section, automatically rise.
Packing And Shipping
Packing according to your requirements, such as wooden cases: your machine is always wrapped completely and securely in film
Or delivered simultaneously in sturdy fumigation-free boxes or 20'/40' containers. We will take care of each machine for you.
1. Pre-sale services:
Act as a good adviser and assistant of clients, enable them to get rich and generous returns on their investments.
1.. Select equipment model;
2.. Design and manufacture products according to clients' special requirement;
3.. Train technical personnel for clients.
2. Services during the sale:
Respect clients, devote ourselves to improving the total value of clients.
1.. Pre-check and accept products ahead of delivery;
2.. Help clients to draft solving plans.
3. After-sale services:
Provide considerate services to minimize clients' worries.
1.. Assist clients to prepare for the first construction scheme;
2.. Install and debug the equipment;
3.. Train the first-line operators;
4.. Examine the equipment;
5.. Take initiative to eliminate the troubles rapidly;
6.. Provide perfect service;
7.. Provide technical exchanging.
Company Introduction
Jinan Mingde Machinery Manufacturing Co., Ltd. has a very good team, we have a strong technical team, after-sales team, sales team, our engineers have more than 10 years of experience, and we will provide overseas debugging services.
